AKFCS系列1/16磚模塊電源

產品概述主要特點 規格型號

AKFCS系列1/16磚模塊電源

AKFCS系列1/16磚模塊電源

AKFCS系列1/16磚模塊電源

非國產磚型DC/DC電源

AKFCS系列1/16磚模塊電源

1/16磚型尺寸：36.5×26.5×12.7mm
功率密度：100W
轉換效率：91%（typ.）
源電壓效應：±0.5%
負載效應：±0.5%
固定的開關頻率：200KHz（typ.）
隔離電壓：1500Vdc

Features

主要特點

ON/OFF使能控制

01

PCB嵌入式平面變壓器

02

輸入、輸出過欠壓保護

03

打嗝模式過載短路保護

04

自恢復過溫保護

05

Model

規格型號

額定輸入電壓

輸入電壓范圍

額定輸出電壓

輸出電流

輸出功率

紋波峰峰值

效率

型號

18Vdc

(9~40)Vdc

3.3V

0~10A

33W

50mV

89.5%

AKFCS18N3V3H10N

18Vdc

(9~40)Vdc

5V

0~10A

50W

50mV

89.5%

AKFCS18N5H10N

18Vdc

(9~40)Vdc

12V

0~4A

50W

120mV

89.0%

AKFCS18N12H4N

18Vdc

(9~40)Vdc

20V

0~4A

80W

200mV

89.0%

AKFCS18N20H4N

18Vdc

(9~40)Vdc

24V

0~2.1A

50W

240mV

89.0%

AKFCS18N24H2N

18Vdc

(9~40)Vdc

28V

0~2A

56W

280mV

89.0%

AKFCS18N28H2N

28Vdc

(16~40)Vdc

3.3V

0~20A

66W

50mV

89.0%

AKFCS28N3V3H20N

28Vdc

(16~40)Vdc

5V

0~20A

100W

50mV

89.0%

AKFCS28N5H20N

28Vdc

(16~40)Vdc

12V

0~8.3A

100W

120mV

89.0%

AKFCS28N12H8A3N

28Vdc

(16~40)Vdc

6.5V

0~11A

70W

100mV

91.0%

AKFCS28N6V5H11N

28Vdc

(16~40)Vdc

24V

0~4.2A

100W

240mV

89.0%

AKFCS24N24H4N

28Vdc

(16~40)Vdc

28V

0~2A

56W

180mV

91.0%

AKFCS28N28H2N

48Vdc

(36~75)Vdc

3.3V

0~20A

66W

50mV

89.0%

AKFCS48N3V3H20N

48Vdc

(36~75)Vdc

5V

0~20A

100W

50mV

89.0%

AKFCS48N5H20N

48Vdc

(36~75)Vdc

6.5V

0~6A

40W

150mV

89.0%

AKFCS48N6V5H6N

48Vdc

(36~75)Vdc

12V

0~8.3A

100W

120mV

89.0%

AKFCS48N12H8A3N

48Vdc

(36~75)Vdc

24V

0~4.2A

100W

240mV

89.0%

AKFCS48N24H4N

48Vdc

(36~75)Vdc

28V

0~2A

56W

180mV

91.0%

AKFCS48N28H2N

270Vdc

(200~425)Vdc

3.3V

0~9.1A

30W

50mV

87.0%

AKFCS270N3V3H9N

270Vdc

(200~425)Vdc

5V

0~6A

30W

100mV

87.0%

AKFCS270N5H6N

270Vdc

(200~425)Vdc

6.5V

0~4.6A

30W

100mV

87.0%

AKFCS270N6V5H4A6N

270Vdc

(200~425)Vdc

9V

0~4.5A

40W

100mV

87.0%

AKFCS270N9H4A5N

270Vdc

(200~425)Vdc

12V

0~3.4A

40W

120mV

90.0%

AKFCS270N12H3A4N

270Vdc

(200~425)Vdc

15V

0~2.7A

40W

150mV

87.0%

AKFCS270N15H2A7N

270Vdc

(200~425)Vdc

18V

0~2.2A

40W

180mV

87.0%

AKFCS270N18H2N

270Vdc

(200~425)Vdc

24V

0~1.7A

40W

240mV

87.0%

AKFCS270N24H1A7N

270Vdc

(200~425)Vdc

28V

0~1.4A

40W

240mV

87.0%

AKFCS270N28H1A4N

270Vdc

(200~425)Vdc

36V

0~1.1A

40W

360mV

87.0%

AKFCS270N36H1N

270Vdc

(200~425)Vdc

48V

0~0.83A

40W

400mV

87.0%

AKFCS270N48H8N
